PNP-Creator V1.02 Software released!

Mon 19 Oct 2020

Our new PNP-Creator job preparation softare is a real WSWYG editor to setup all parameters during job preparation.

Gerber file import show PCB representation.

Feeder file import is used for feeder assignment.

We are able to import a wide range of PNP files thanks to our flexible import module using profiles for each PNP file type.

Software section changed!

Mon 28 Sep 2020

You can find all software information now under software menu point.

Dot-Maker and PNP-Creator now moved to software menu.

Vision Placer V2.055 software update released

Wed 16 Sep 2020

PNP-Creator Software released!

Wed 16 Sep 2020

Our new PNP-Creator job preparation softare is a real WSWYG editor to setup all parameters during job preparation.

Gerber file import show PCB representation.

Feeder file import is used for feeder assignment.

We are able to import a wide range of PNP files thanks to our flexible import module using profiles for each PNP file type.

All trademarks remain property of their respective holders, and are used only to directly describe the products being provided. Their use in no way indicates any relationship between SMALLSMT and the holders of said trademarks.

Bestückungsautomat für Prototypen und Kleinserien

Wir bauen Bestückungsmaschinen für die zuverlässige Bestückung von Leiterplatten, für Prototypen und Kleinserien. Abhängig von Ihren Ansprüchen bieten wir einfache Produkte bis zu den HP (High Precision) Bestückungsautomaten die über AC Servos und Kugelumlaufspindeln eine absolute Positionierung ermöglichen.

Pick and Place Machine for prototyping and smaller batches

We are manufacturer for Pick & Place machines used for professional assembly of pcb for prototypes and small batches. Depending on your demands we offer simple pick and place machines up to our High Precision HP machines. For HP pnp machines we us AC servo motors and ball screw spindles to achieve closed loop positioning.

Máquina Pick and Place para prototipos y pequeñas producciones.

Somos fabricantes de máquinas Pick and Place usadas por profesionales para prototipos y pequeñas producciones. Dependiendo de sus demandas podemos ofrecer desde máquinas Pick and Place básicas hasta nuestras máquinas HP de alta precisión. Para nuestras HP pnp usamos servo motores de AC con husillo para conseguir un control de posición de lazo cerrado.
